AUSTLIFT Stubby Eye Bolt

Swivel Eye Bolt Points are accordingly to AS2318 for the swivel component.Used as a swiveling load ring able to swivel 360° with a pivot of 90°. Made from G100 alloy steel with Orange painted finish, manufactured with an elongated ring in metric thread sizes 8mm to 20mm.

• Marked with work load limit in tonne, nominal size in millimetre, quality mark and supplier identification.
• Designed by forged alloy steel, quenched and tempered.
• 360° rotation with 90° pivot function.
• Rated at 100% at 90° angle.
• 100% magnaflux crack detection.
• Proof tested in 2 stages.

  1. 1.25 x working load limit with ball bearing included.
  2. Removal of ball bearing that is subject to damages, then 2x working load limit is applied.

• Test certificate available upon request.

In Stock
